|Safe Max. Load||Deflection at Max. Load||User Specified Deflection Limit||Max. Load for Deflection Limit||Critical Member|
|8070 lbs.||0.15 in.||—||—||Top Deckboard|
Pallet Service Life Analysis
The Pallet Service Life Analysis simulates a series of forces and impacts applied to the pallet during each handling cycle. The frequency and severity of these impacts are estimates based on laboratory measurements, warehouse observations, and the Virginia Tech FasTrack Handling Cycle. The resistance to damage and the damage level requiring component repair or replacement are based on laboratory testing and the NWPCA Uniform Standard for Wood Pallets.
Service Environment Conditions
Average Handling and Treatment, Medium-Duty Loads, Dry Environment (EMC <= 19%)
Predicted Service Life
In the Handling Simulation, Damage requiring Component Repair occurred during First Cycle.
*Note: Lab Stacking Strength formula is not intended to replace laboratory testing! Actual results may be higher or lower than the calculated strength. A “Safety Factor of 4” has been used to calculate the Lab Stacking Strength.
